Denso 23250-37020 · Serviced & Flow-Tested

Toyota Prius / Lexus CT200h 1.8L Hybrid Fuel Injector Cleaning & Flow Testing

The Denso 23250-37020 is a MPFI hybrid (port injection) fuel injector used in Toyota Prius, Prius V and Prius Plug-In 1.8L (2010-2015), plus Lexus CT200h 1.8L (2011-2015) — all the 2ZR-FXE hybrid engine. Denso EV14 with a 12-hole nozzle. Short-trip hybrid running is exactly the duty cycle that fouls these.. We ultrasonic-clean and flow-test injectors like this one in our shop, then send back before-and-after data so you know exactly what you're getting.

ManufacturerDenso
Part number23250-37020
TypeMPFI hybrid (port injection)
ConnectorDenso (12-hole nozzle)

Our measured results

These are the actual before-and-after numbers from our flow bench for the Denso 23250-37020 — not published estimates.

Tested in our shop4 injector(s) @ 40.0 psi
Measured coil (avg)12.38 Ω
10s open flow (avg)43.5 → 45.0 ml (+3.4%)
60s pulsed flow (avg)42.75 → 43.5 ml
Leak test after cleaning4/4 PASS

Also known as / cross-references

The Denso 23250-37020 is interchangeable with or cross-references to these part numbers:

23209-3702023250-37021297500-1580 (Denso)842-12373

What vehicles use the Denso 23250-37020?

Toyota Prius, Prius V and Prius Plug-In 1.8L (2010-2015), plus Lexus CT200h 1.8L (2011-2015) — all the 2ZR-FXE hybrid engine. Denso EV14 with a 12-hole nozzle. Short-trip hybrid running is exactly the duty cycle that fouls these.

How we service the Denso 23250-37020

Ultrasonic clean, backflush, before-and-after flow and leak test, spray check, tested at 40 psi, new seals and filter baskets where available. Full process on our services page.

Frequently asked questions

What did the 23250-37020 flow at on your bench?
On our bench, 4 23250-37020 injectors averaged 43.5 ml open flow before cleaning and 45.0 ml after, tested at 40.0 psi.

Send in your 23250-37020 injectors

Mail-in cleaning and flow testing with a full before/after report. 2-injector minimum, $15 flat round-trip shipping.

Get Started
